Olympic Sports Image Classification with EfficientNetV2

Leave a Comment / Image Classification

Introduction

Image classification is one of the most exciting applications of computer vision. It powers technologies in sports analytics, autonomous driving, healthcare diagnostics, and more.

In this project, we take you through a complete, end-to-end workflow for classifying Olympic sports images — from raw data to real-time predictions — using EfficientNetV2S, a state-of-the-art deep learning model.

Our journey is divided into three clear steps:

Dataset Preparation – Organizing and splitting images into training and testing sets.
Model Training – Fine-tuning EfficientNetV2S on the Olympics dataset.
Model Inference – Running real-time predictions on new images.

Starting with the Olympic Games Event Dataset, we:

Split images into train, validation, and test sets.
Fine-tune EfficientNetV2 with a custom classification head.
Use data augmentation and training callbacks for best results.
Evaluate model accuracy and loss.
Predict and label new images with OpenCV.

The code is easy to adapt for any custom dataset, making it a practical template for real-world computer vision projects.

Watch the full tutorial here : https://youtu.be/wQgGIsmGpwo

You can download the dataset here : https://www.kaggle.com/datasets/yousefidris/ogedolympic-games-event-dateset

You can download the full code here : https://ko-fi.com/s/a24e1b1bd1

You can find more tutorials, and join my newsletter here : https://eranfeit.net/

Step 1 – Preparing and Splitting the Dataset

Before training a model, we need to organize the dataset. The Olympics dataset we use contains folders, each representing a different sport (e.g., swimming, gymnastics, athletics).

To ensure accurate evaluation:

Training set (90%) – Used for teaching the model.
Testing set (10%) – Used for measuring performance on unseen data.

The dataset split keeps the original folder structure so the model retains class labels. Shuffling images ensures a fair and balanced distribution between training and testing sets.

# ================================
# Code 1: Dataset Splitter (Olympics dataset example)
# ================================

# --- 1.1 Imports & high-level settings ---

# 1.1.1 Import standard libraries for filesystem work, copying files, and randomness
import os
import shutil
import random

# 1.1.2 Define the intended split ratio: 90% train, 10% test (descriptive comment)
# 90% of the dataset -> train folder
# 10% of the dataset -> test folder


# --- 1.2 Configure dataset paths ---

# 1.2.1 Path to the main dataset folder (source)
main_folder = 'e:/data-sets/olympics'

# 1.2.2 Paths to train and test destination folders
train_folder = 'e:/data-sets/olympics-train'
test_folder = 'e:/data-sets/olympics-test'


# --- 1.3 Ensure destination folders exist ---

# 1.3.1 Create train folder if missing
os.makedirs(train_folder , exist_ok=True)
# 1.3.2 Create test folder if missing
os.makedirs(test_folder , exist_ok=True)


# --- 1.4 Discover class subfolders in the source ---

# 1.4.1 Initialize list to hold class folder paths
subfolders = []

# 1.4.2 Loop through items in main dataset folder
for f in os.scandir(main_folder):
    # 1.4.3 If it's a folder (class/category), add to list
    if f.is_dir():
        subfolders.append(f.path)


# --- 1.5 Define split percentage ---

# 1.5.1 Percentage of files for training set
train_precentage = 90


# --- 1.6 Per-class processing: create dirs, list/shuffle files, compute split ---

# 1.6.1 Loop over each class/category subfolder
for subfolder in subfolders:

    # 1.6.2 Extract class folder name
    subfolder_name = os.path.basename(subfolder)

    # 1.6.3 Paths for train/test subfolders for this class
    train_subfolder = os.path.join(train_folder , subfolder_name)
    test_subfolder = os.path.join(test_folder , subfolder_name)

    # 1.6.4 Create class subfolder in train/test directories
    os.makedirs(train_subfolder , exist_ok=True)
    os.makedirs(test_subfolder , exist_ok=True)

    # 1.6.5 List all files in this class folder
    files = [f.path for f in os.scandir(subfolder) if f.is_file()]

    # 1.6.6 Randomize file order
    random.shuffle(files)

    # 1.6.7 Calculate number of train files
    num_train_files = int( len(files) * (train_precentage / 100) )

    # 1.6.8 Copy train files
    for file in files[:num_train_files]:
        shutil.copy(file, os.path.join(train_subfolder , os.path.basename(file)))

    # 1.6.9 Copy test files
    for file in files[num_train_files:]:
        shutil.copy(file, os.path.join(test_subfolder , os.path.basename(file)))


# --- 1.7 Final status message ---

# 1.7.1 Print confirmation
print("Finish copy the files to Train and Test subfolder")

# ================================ # Code 1: Dataset Splitter (Olympics dataset example) # ================================  # --- 1.1 Imports & high-level settings ---  # 1.1.1 Import standard libraries for filesystem work, copying files, and randomness import os  import shutil  import random   # 1.1.2 Define the intended split ratio: 90% train, 10% test (descriptive comment) # 90% of the dataset -> train folder  # 10% of the dataset -> test folder    # --- 1.2 Configure dataset paths ---  # 1.2.1 Path to the main dataset folder (source) main_folder = 'e:/data-sets/olympics'  # 1.2.2 Paths to train and test destination folders train_folder = 'e:/data-sets/olympics-train' test_folder = 'e:/data-sets/olympics-test'   # --- 1.3 Ensure destination folders exist ---  # 1.3.1 Create train folder if missing os.makedirs(train_folder , exist_ok=True) # 1.3.2 Create test folder if missing os.makedirs(test_folder , exist_ok=True)   # --- 1.4 Discover class subfolders in the source ---  # 1.4.1 Initialize list to hold class folder paths subfolders = []  # 1.4.2 Loop through items in main dataset folder for f in os.scandir(main_folder):     # 1.4.3 If it's a folder (class/category), add to list     if f.is_dir():         subfolders.append(f.path)   # --- 1.5 Define split percentage ---  # 1.5.1 Percentage of files for training set train_precentage = 90   # --- 1.6 Per-class processing: create dirs, list/shuffle files, compute split ---  # 1.6.1 Loop over each class/category subfolder for subfolder in subfolders:      # 1.6.2 Extract class folder name     subfolder_name = os.path.basename(subfolder)      # 1.6.3 Paths for train/test subfolders for this class     train_subfolder = os.path.join(train_folder , subfolder_name)     test_subfolder = os.path.join(test_folder , subfolder_name)      # 1.6.4 Create class subfolder in train/test directories     os.makedirs(train_subfolder , exist_ok=True)     os.makedirs(test_subfolder , exist_ok=True)      # 1.6.5 List all files in this class folder     files = [f.path for f in os.scandir(subfolder) if f.is_file()]      # 1.6.6 Randomize file order     random.shuffle(files)      # 1.6.7 Calculate number of train files     num_train_files = int( len(files) * (train_precentage / 100) )      # 1.6.8 Copy train files     for file in files[:num_train_files]:         shutil.copy(file, os.path.join(train_subfolder , os.path.basename(file)))      # 1.6.9 Copy test files     for file in files[num_train_files:]:         shutil.copy(file, os.path.join(test_subfolder , os.path.basename(file)))          # --- 1.7 Final status message ---  # 1.7.1 Print confirmation print("Finish copy the files to Train and Test subfolder")

You can download the full code here : https://ko-fi.com/s/a24e1b1bd1

Step 2 – Training with EfficientNetV2S

With the dataset ready, it’s time to train the model. Instead of starting from scratch, we use transfer learning with EfficientNetV2S, which is already trained on millions of images from ImageNet.

Here’s how we adapt it to our project:

Keep the feature extraction layers from EfficientNetV2S.
Add custom layers to classify our specific sports categories.
Fine-tune the model so it learns both general image features and sport-specific patterns.

To improve generalization, we apply data augmentation during training — random flips, zoom, and shearing — so the model learns to handle different camera angles, lighting conditions, and athlete positions.

We train for multiple epochs, using tools like EarlyStopping and ModelCheckpoint to save the best version of the model and avoid overfitting.

# ================================
# Code 2: Training EfficientNetV2S on Olympics Dataset
# ================================

# --- 2.1 Imports & configuration ---

# 2.1.1 Import TensorFlow and Keras layers API
import tensorflow as tf
from tensorflow.keras import layers
from tensorflow.keras.preprocessing.image import ImageDataGenerator

# 2.1.2 Import supporting libraries
import numpy as np
import os
import matplotlib.pyplot as plt

# 2.1.3 Define target image size (all images resized to 224x224)
IMAGE_SIZE = 224


# --- 2.2 Load class names & count ---

# 2.2.1 Path to dataset folder containing class subfolders
imageFolder = 'e:/data-sets/olympics'

# 2.2.2 Get a list of class names (folder names)
CLASSES = os.listdir(imageFolder)

# 2.2.3 Count number of classes
num_classes = len(CLASSES)

# 2.2.4 Print class names
print(CLASSES)
# 2.2.5 Print number of classes
print(num_classes)


# --- 2.3 Load pre-trained base model (EfficientNetV2S) ---

# 2.3.1 Load EfficientNetV2S without the top classification layer
# weights='imagenet' uses ImageNet pretrained weights
# input_shape matches resized images
# include_top=False removes the 1000-class output layer
base_model = tf.keras.applications.EfficientNetV2S(
    weights='imagenet',
    input_shape=(IMAGE_SIZE, IMAGE_SIZE, 3),
    include_top=False
)

# 2.3.2 Allow all layers to be trainable (fine-tuning)
base_model.trainable = True


# --- 2.4 Build the full model ---

# 2.4.1 Create a sequential model combining the base and new layers
model = tf.keras.Sequential([
    base_model,                                # Pre-trained feature extractor
    layers.GlobalAveragePooling2D(),           # Pool features to vector
    layers.Dense(1024, activation='relu'),     # Dense layer for learning patterns
    layers.Dropout(0.5),                       # Dropout for regularization
    layers.Dense(num_classes, activation='softmax')  # Output layer for our classes
])


# --- 2.5 Compile the model ---

# 2.5.1 Import Adam optimizer
from tensorflow.keras.optimizers import Adam

# 2.5.2 Create Adam optimizer with a small learning rate for transfer learning
adam_opt = Adam(learning_rate = 0.0001)

# 2.5.3 Compile model with categorical crossentropy (multi-class classification)
model.compile(
    optimizer=adam_opt,
    loss='categorical_crossentropy',
    metrics=['accuracy']
)


# --- 2.6 Data generators (augmentation for training) ---

# 2.6.1 Create training data generator with augmentation
train_datagen = ImageDataGenerator(
    rescale=1./255,          # Normalize pixel values
    shear_range=0.2,         # Random shearing
    zoom_range=0.2,          # Random zoom
    horizontal_flip=True     # Flip images horizontally
)

# 2.6.2 Create testing/validation data generator (no augmentation, only rescale)
test_datagen = ImageDataGenerator(rescale=1./255)

# 2.6.3 Paths to split datasets
train_folder = 'e:/data-sets/olympics-train'
test_folder = 'e:/data-sets/olympics-test'

# 2.6.4 Training set generator
train_generator = train_datagen.flow_from_directory(
    train_folder,
    target_size=(IMAGE_SIZE, IMAGE_SIZE),
    batch_size=8,
    class_mode='categorical',
    color_mode='rgb',
    shuffle=True
)

# 2.6.5 Validation/test set generator
test_generator = test_datagen.flow_from_directory(
    test_folder,
    target_size=(IMAGE_SIZE, IMAGE_SIZE),
    batch_size=8,
    class_mode='categorical',
    color_mode='rgb'
)


# --- 2.7 Training parameters & callbacks ---

# 2.7.1 Number of epochs for training
EPOCHS = 300

# 2.7.2 Filepath to save the best model
best_model_file = 'e:/temp/olympics-EfficientNetV2.h5'

# 2.7.3 Import callbacks
from keras.callbacks import ModelCheckpoint, ReduceLROnPlateau, EarlyStopping

# 2.7.4 Define callbacks
callbacks = [
    # Save the best model based on validation accuracy
    ModelCheckpoint(best_model_file, verbose=1, save_best_only=True, monitor="val_accuracy"),
    # Reduce learning rate if validation accuracy plateaus
    ReduceLROnPlateau(monitor="val_accuracy", patience=25, factor=0.1, verbose=1, min_lr=1e-6),
    # Stop training early if no improvement
    EarlyStopping(monitor="val_accuracy", patience=25, verbose=1)
]


# --- 2.8 Train the model ---

# 2.8.1 Fit model on training data with validation
result = model.fit(
    train_generator,
    epochs=EPOCHS,
    validation_data=test_generator,
    callbacks=callbacks
)


# --- 2.9 Find best validation accuracy ---

# 2.9.1 Epoch index of best validation accuracy
best_val_acc_epoch = np.argmax(result.history['val_accuracy'])

# 2.9.2 Best validation accuracy value
best_val_acc = result.history['val_accuracy'][best_val_acc_epoch]

# 2.9.3 Print best validation accuracy
print("Best validation accuracy : " + str(best_val_acc))


# --- 2.10 Plot accuracy curves ---

# 2.10.1 Plot training vs validation accuracy
plt.plot(result.history['accuracy'], label='train acc')
plt.plot(result.history['val_accuracy'], label='val acc')
plt.legend()
plt.show()


# --- 2.11 Plot loss curves ---

# 2.11.1 Plot training vs validation loss
plt.plot(result.history['loss'], label='train loss')
plt.plot(result.history['val_loss'], label='val loss')
plt.legend()
plt.show()

# ================================ # Code 2: Training EfficientNetV2S on Olympics Dataset # ================================  # --- 2.1 Imports & configuration ---  # 2.1.1 Import TensorFlow and Keras layers API import tensorflow as tf  from tensorflow.keras import layers from tensorflow.keras.preprocessing.image import ImageDataGenerator   # 2.1.2 Import supporting libraries import numpy as np  import os import matplotlib.pyplot as plt   # 2.1.3 Define target image size (all images resized to 224x224) IMAGE_SIZE = 224   # --- 2.2 Load class names & count ---  # 2.2.1 Path to dataset folder containing class subfolders imageFolder = 'e:/data-sets/olympics'  # 2.2.2 Get a list of class names (folder names) CLASSES = os.listdir(imageFolder)  # 2.2.3 Count number of classes num_classes = len(CLASSES)  # 2.2.4 Print class names print(CLASSES) # 2.2.5 Print number of classes print(num_classes)   # --- 2.3 Load pre-trained base model (EfficientNetV2S) ---  # 2.3.1 Load EfficientNetV2S without the top classification layer # weights='imagenet' uses ImageNet pretrained weights # input_shape matches resized images # include_top=False removes the 1000-class output layer base_model = tf.keras.applications.EfficientNetV2S(     weights='imagenet',      input_shape=(IMAGE_SIZE, IMAGE_SIZE, 3),      include_top=False )  # 2.3.2 Allow all layers to be trainable (fine-tuning) base_model.trainable = True   # --- 2.4 Build the full model ---  # 2.4.1 Create a sequential model combining the base and new layers model = tf.keras.Sequential([      base_model,                                # Pre-trained feature extractor     layers.GlobalAveragePooling2D(),           # Pool features to vector     layers.Dense(1024, activation='relu'),     # Dense layer for learning patterns     layers.Dropout(0.5),                       # Dropout for regularization     layers.Dense(num_classes, activation='softmax')  # Output layer for our classes ])   # --- 2.5 Compile the model ---  # 2.5.1 Import Adam optimizer from tensorflow.keras.optimizers import Adam  # 2.5.2 Create Adam optimizer with a small learning rate for transfer learning adam_opt = Adam(learning_rate = 0.0001)  # 2.5.3 Compile model with categorical crossentropy (multi-class classification) model.compile(     optimizer=adam_opt,      loss='categorical_crossentropy',      metrics=['accuracy'] )   # --- 2.6 Data generators (augmentation for training) ---  # 2.6.1 Create training data generator with augmentation train_datagen = ImageDataGenerator(     rescale=1./255,          # Normalize pixel values     shear_range=0.2,         # Random shearing     zoom_range=0.2,          # Random zoom     horizontal_flip=True     # Flip images horizontally )  # 2.6.2 Create testing/validation data generator (no augmentation, only rescale) test_datagen = ImageDataGenerator(rescale=1./255)  # 2.6.3 Paths to split datasets train_folder = 'e:/data-sets/olympics-train' test_folder = 'e:/data-sets/olympics-test'  # 2.6.4 Training set generator train_generator = train_datagen.flow_from_directory(     train_folder,      target_size=(IMAGE_SIZE, IMAGE_SIZE),     batch_size=8,     class_mode='categorical',     color_mode='rgb',     shuffle=True )  # 2.6.5 Validation/test set generator test_generator = test_datagen.flow_from_directory(     test_folder,      target_size=(IMAGE_SIZE, IMAGE_SIZE),     batch_size=8,     class_mode='categorical',     color_mode='rgb' )   # --- 2.7 Training parameters & callbacks ---  # 2.7.1 Number of epochs for training EPOCHS = 300  # 2.7.2 Filepath to save the best model best_model_file = 'e:/temp/olympics-EfficientNetV2.h5'  # 2.7.3 Import callbacks from keras.callbacks import ModelCheckpoint, ReduceLROnPlateau, EarlyStopping  # 2.7.4 Define callbacks callbacks = [     # Save the best model based on validation accuracy     ModelCheckpoint(best_model_file, verbose=1, save_best_only=True, monitor="val_accuracy"),     # Reduce learning rate if validation accuracy plateaus     ReduceLROnPlateau(monitor="val_accuracy", patience=25, factor=0.1, verbose=1, min_lr=1e-6),     # Stop training early if no improvement     EarlyStopping(monitor="val_accuracy", patience=25, verbose=1) ]   # --- 2.8 Train the model ---  # 2.8.1 Fit model on training data with validation result = model.fit(     train_generator,      epochs=EPOCHS,      validation_data=test_generator,      callbacks=callbacks )   # --- 2.9 Find best validation accuracy ---  # 2.9.1 Epoch index of best validation accuracy best_val_acc_epoch = np.argmax(result.history['val_accuracy'])  # 2.9.2 Best validation accuracy value best_val_acc = result.history['val_accuracy'][best_val_acc_epoch]  # 2.9.3 Print best validation accuracy print("Best validation accuracy : " + str(best_val_acc))   # --- 2.10 Plot accuracy curves ---  # 2.10.1 Plot training vs validation accuracy plt.plot(result.history['accuracy'], label='train acc') plt.plot(result.history['val_accuracy'], label='val acc') plt.legend() plt.show()   # --- 2.11 Plot loss curves ---  # 2.11.1 Plot training vs validation loss plt.plot(result.history['loss'], label='train loss') plt.plot(result.history['val_loss'], label='val loss') plt.legend() plt.show()

You can download the full code here : https://ko-fi.com/s/a24e1b1bd1

Step 3 – Making Real-Time Predictions

The final step is to use the trained model to classify new, unseen images.

Our test image :

Waterpolo test image

The prediction process includes:

Preprocessing – Resize the image, normalize pixel values, and prepare it in the same way as during training.
Prediction – The model outputs probabilities for each class.
Result Extraction – The class with the highest probability becomes the prediction.
Visualization – The predicted sport is overlaid on the image and displayed or saved.

This makes the system ready for practical use, instantly recognizing the sport in any given image.

import tensorflow as tf
import cv2
import os

from keras.utils import load_img , img_to_array
import numpy as np

IMAGE_SIZE = 224

# get the classes
imageFolder = 'e:/data-sets/olympics'
CLASSES = os.listdir(imageFolder)
num_classes = len(CLASSES)

best_model_file = 'e:/temp/olympics-EfficientNetV2.h5'
model = tf.keras.models.load_model(best_model_file)

def prepareImage(pathForImage) :
    image = load_img(pathForImage , target_size=(IMAGE_SIZE, IMAGE_SIZE))
    img_result = img_to_array(image)
    img_result = np.expand_dims(img_result , axis=0)
    img_result = img_result / 255.
    return img_result


testImagePath = "Best-image-classification-models/EfficientNetv2-Build-Model-Custom-Dataset/waterpolo-test-image.png"
img = cv2.imread(testImagePath)

ImgForModel = prepareImage(testImagePath)
resultArray = model.predict(ImgForModel , verbose=1)
answer = np.argmax(resultArray , axis=1)

print(answer)
index = answer[0]
desc = CLASSES[index]

print("The predicted class is : " + desc)


scale_precent = 60
width = int(img.shape[1] * scale_precent / 100)
height = int(img.shape[0] * scale_precent / 100)
dim = (width, height)
resized = cv2.resize(img, dim , interpolation = cv2.INTER_AREA)

cv2.putText(resized , desc , (10,100), cv2.FONT_HERSHEY_SIMPLEX, 1.6, (255,0,0), 3 , cv2.LINE_AA)

cv2.imwrite("e:/temp/waterpolo.png" , resized)

cv2.imshow('img', resized)
cv2.waitKey(0)

import tensorflow as tf  import cv2  import os   from keras.utils import load_img , img_to_array  import numpy as np   IMAGE_SIZE = 224  # get the classes  imageFolder = 'e:/data-sets/olympics' CLASSES = os.listdir(imageFolder) num_classes = len(CLASSES)  best_model_file = 'e:/temp/olympics-EfficientNetV2.h5' model = tf.keras.models.load_model(best_model_file)  def prepareImage(pathForImage) :     image = load_img(pathForImage , target_size=(IMAGE_SIZE, IMAGE_SIZE))     img_result = img_to_array(image)     img_result = np.expand_dims(img_result , axis=0)     img_result = img_result / 255.     return img_result   testImagePath = "Best-image-classification-models/EfficientNetv2-Build-Model-Custom-Dataset/waterpolo-test-image.png" img = cv2.imread(testImagePath)  ImgForModel = prepareImage(testImagePath) resultArray = model.predict(ImgForModel , verbose=1) answer = np.argmax(resultArray , axis=1)  print(answer) index = answer[0] desc = CLASSES[index]  print("The predicted class is : " + desc)   scale_precent = 60 width = int(img.shape[1] * scale_precent / 100) height = int(img.shape[0] * scale_precent / 100) dim = (width, height) resized = cv2.resize(img, dim , interpolation = cv2.INTER_AREA)  cv2.putText(resized , desc , (10,100), cv2.FONT_HERSHEY_SIMPLEX, 1.6, (255,0,0), 3 , cv2.LINE_AA)  cv2.imwrite("e:/temp/waterpolo.png" , resized)  cv2.imshow('img', resized) cv2.waitKey(0)

You can download the full code here : https://ko-fi.com/s/a24e1b1bd1

Connect

☕ Buy me a coffee — https://ko-fi.com/eranfeit

🖥️ Email : feitgemel@gmail.com

🌐 https://eranfeit.net

🤝 Fiverr : https://www.fiverr.com/s/mB3Pbb

Enjoy,

Eran

Leave a Comment Cancel Reply

error: Content is protected !!
